3D Four Wheel Alignment Machine Automatic Wheel Aligner

Overview

The YL-86 3D Car Wheel Alignment Machine is a high-precision automotive diagnostic system designed for fast and accurate vehicle alignment. Equipped with an 8-megapixel Sony optical camera system and dual high-definition displays (32-inch and 19-inch), this professional aligner utilizes the Johnbean operating system with free updates. Complete with an HP printer, durable 11-25 inch wheel clamps, high-definition target boards, and precision turntables, it delivers reliable measurement for tire repair shops, automotive workshops, and dealerships.

Key Features

• Dual HD Displays: 32-inch main screen and 19-inch secondary monitor provide clear, multi-angle operational feedback.
• Sony Optical Imaging: Dual 8-megapixel Sony HD cameras ensure rapid target capture and accurate data processing.
• Johnbean System: Reliable alignment software with lifetime free database updating.
• Comprehensive Alignment Parameters: Measures Toe, Camber, Caster, Setback, SAI, Thrust Angle, Axle Offset, Wheel Offset, Single Wheel, and traditional positioning geometry.
• Complete Standard Hardware: Comes equipped with an HP printer for report printouts, 4 heavy-duty 11-25 inch wheel clamps, 4 target plates (22x22 cm), and 2 turntables.

Technical Specifications

• Model: YL-86
• Camera: 8-Megapixel Sony HD Camera
• Display: Dual HD Monitors (32-inch and 19-inch)
• Operating System: Johnbean System with Free Updating
• Wheel Clamp Range: 11 - 25 inches (4 pcs)
• Target Dimensions: 22 x 22 cm (4 pcs)
• Turntables: 2 pcs
• Printer: 1 pc HP Printer
• Measurement Parameters: Toe, Camber, Caster, Setback, SAI, Thrust Angle, Axle Offset, Wheel Offset, Single Wheel


Package & Shipping Details

• Package 1 Dimensions: 350 x 300 x 2920 mm
• Package 2 Dimensions: 760 x 860 x 1050 mm
• Total Gross Weight: 200 kg
• Total Volume: 1.1 CBM
