Multiple Models of Vehicles Auto Body Frame Machine Car Chassis Straightening Bench Collision Repair

The BOSCAR Industrial Auto Body Frame Machine and Chassis Straightening Bench Series (featuring models FR-2000, FR-3500, and KW-5000) is engineered for professional collision repair centers, automotive body shops, and vehicle chassis realignment facilities. Built with high-strength structural steel and heavy-duty manganese steel platforms, these bench systems deliver up to 3,500 kg lifting capacity, a high-pressure 70 Mpa hydraulic system, and versatile 100 KN to 150 KN pulling towers with 360-degree rotational pulling capability for precision multi-point structural corrections.

Key Features

• 3,500 kg Heavy-Duty Lifting Capacity: Robust hydraulic lifting mechanism easily supports passenger cars, SUVs, and light commercial vehicles up to 3,500 kg.
• High-Pressure 70 Mpa Hydraulic Power: Industrial 70 Mpa (10,000 psi) hydraulic operating pressure ensures dependable, consistent power for heavy frame pulling and chassis straightening.
• 360-Degree Multi-Angle Pulling Towers: Flexible pulling towers rotate smoothly 360 degrees around the heavy-duty perimeter platform, allowing technicians to pull accurately from any angle or direction.
• Versatile Pulling Force Options (100 KN / 150 KN): Dual-tower (FR-2000), four-tower (FR-3500), and multi-tower girder calibrator (KW-5000) configurations deliver massive pulling force from 100 KN (10 ton) up to 150 KN to straighten severe structural impacts.
• Precision Platform & Tilting Mechanism: Heavy-duty 5.6-meter workbenches provide ample working space, with the KW-5000 featuring high-strength 10 mm manganese steel plate construction and a single hydraulic tilting system for effortless vehicle loading and positioning.

Technical Specifications

Model FR-2000 (Two Towers Frame Machine)

• Tower Configuration: Two pulling towers (360° working range)
• Max. Tension Force: 100 KN
• Max. Lifting Weight (One Side): 3,500 kg
• Hydraulic System Max. Pressure: 70 Mpa
• Required Air Pressure: 0.8 Mpa
• Workbench Dimensions (L x W x H): 5,600 x 2,100 x 520 mm
• Package Volume & Weight: 3.4 CBM, 2,000 kg
• Packaging Breakdown: Package 1#: 560 x 212 x 12 cm (1,150 kg); Package 2#: 225 x 145 x 54 cm (950 kg)

Model FR-3500 (Four Towers Frame Machine)

• Tower Configuration: Four pulling towers (360° working range)
• Max. Tension Force: 150 KN
• Max. Lifting Weight (One Side): 3,500 kg
• Hydraulic System Max. Pressure: 70 Mpa
• Required Air Pressure: 0.8 Mpa
• Workbench Dimensions (L x W x H): 5,600 x 2,100 x 520 mm
• Package Volume & Weight: 5.2 CBM, 2,500 kg
• Packaging Breakdown: Package 1#: 560 x 210 x 12 cm; Package 2#: 225 x 145 x 57 cm; Package 3#: 225 x 145 x 57 cm

Model KW-5000 (Girder Calibrator Frame Machine)

• Tower Configuration: Two circular towers, one square tower, one small tower, and 1 lean arm
• Tower Pulling Capacity: 100 KN (10 ton)
• Max. Lifting Capacity: 3,500 kg
• Hydraulic Power: 70 Mpa (10,000 psi)
• Air Supply Required: 0.8 Mpa
• Platform Dimensions (L x W x H): 5,600 x 2,200 x 550 mm
• Platform Thickness & Material: 120 mm thickness, 10 mm manganese steel plate, single side platform width 600 mm
• Tilting System: Hydraulic single tilting system platform (120 mm)
• Package Volume & Weight: 5.2 CBM, 2,800 kg
• Packaging Breakdown: Package 1#: 560 x 210 x 12 cm; Package 2#: 225 x 145 x 57 cm; Package 3#: 225 x 145 x 57 cm
